TP-Link SG2210XMP-M2, Omada

367.90 €

TP-Link SG2210XMP-M2, Omada

A switch is an active network component that connects individual devices and other network elements. It is designed for managing network traffic. The TP-Link SG2210XMP-M2, Omada is supposed to be installed on the work desk or wall. The model impresses with a switching capacity of 80 Gb/s. The Switch features 8 × RJ-45 ports that facilitate connection with network elements. The switch dimensions are 226 × 131 × 35mm. QoS aka Quality of Service technology makes sure the switch stays within its capacity, and it also lets you set up end station priority. The TP-Link device includes PoE technology that provides power and signal connection to end devices with a single LAN cable. The switch weighs 1150g.

Switch TP-Link SG2210XMP-M2, Omada ...
Switch TP-Link SG2210XMP-M2, Omada ...

Key Features of the TP-Link SG2210XMP-M2, Omada Switch

  • For connecting end devices and other nodes
  • 80 Gb/s switching capacity
  • Offers 8 × RJ-45 ports
  • TP-Link switch is made for worktops or wall installation
  • PoE (Power over Ethernet) technology support
  • QoS (Quality of Service) option
  • VLAN support

Specifications

Type

Design Desktop
Use Home, Company

Functions

Functions Auto-MDI/MDIX, Auto-negotiation, PoE, Port mirroring
Switching layer L2
Advanced network functions QoS (Quality of Service), VLAN, Static line aggregation, LACP line aggregation
Snooping IGMP, DHCP, MLD, ARP
Management and security DoS prevention, Port Security, 802.1X authentication, Network loop detection, ACL
Functions for camera systems Priority mode

Ports

RJ-45 8 ×
SFP+ 2 ×

Number of LAN ports

Number of LAN ports with 2.5 Gbit speed 8
Number of LAN ports with 10 Gbit speed 2

PoE properties

PoE standard 802.3af (PoE), 802.3at (PoE+)
Performance 160 W
Maximum output power per port 30 W
Number of PoE ports 8 ×

Routing

Routing Static routing

Features

Power Supply DC Jack
Maximum number of VLANs 4,096 ×
Features IPv6 Ready

Speed

Switching capacity 80 Gb/s
Packet capacity (64B packets, in million of packets) 59.52 Mpps

Dimensions

Width 226 mm
Height 35 mm
Depth 131 mm

Material

Body material Metal

Operating temperature

Minimum operating temperature 0 °C
Maximum operating temperature 40 °C

Weight

Weight 1,150 g

Power outlet type

Country Czechia, Slovakia, Hungary, Germany, Russia, Austria, Croatia, France, Poland, Romania, Slovenia
Code:  TP26073
Warranty: 60 months
Links: Producer's Website:
Manufacturer information

TP-LINK Czech s.r.o., Pekařská 10a, 15500 Praha 5, Česko, [email protected], www.tp-link.com


TP-LINK Czech, s. r. o., Pekařská 695/10, Jinonice, 155 00 Praha 5, CZ +420 212 812 622 / SK +421 233 006 532, [email protected]
