Type
Use
Company, Camera systems
Functions
Functions
Auto-MDI/MDIX, Auto-negotiation, Plug and play, Port mirroring
Switching layer
L2
Advanced network functions
QoS (Quality of Service), VLAN, Static line aggregation
Management and security
Network loop detection
Functions for camera systems
Priority mode, Isolation mode
Ports
RJ-45
24 ×
10/100/1000Base-T
24
LAN port transmission speed
Number of LAN ports with 1 Gbit speed
24
Features
Power Supply
From the network
Maximum number of VLANs
32 ×
Speed
Switching capacity
48 Gb/s
Packet capacity (64B packets, in million of packets)
35.7 Mpps
Dimensions
Width
294 mm
Height
44 mm
Depth
140 mm
Frame width
482.6 mm
Material
Body material
Metal
Operating temperature
Minimum operating temperature
-5 °C
Maximum operating temperature
50 °C
Weight
Weight
1,270 g
Power outlet type
Country
Czechia, Slovakia, Hungary, Germany, Russia, Austria, Croatia, France, Poland, Romania, Slovenia
